Semiconductor diode I-V characteristics
The I-V characteristics of a semiconductor diode describe the relationship between the current (I) flowing through the diode and the applied voltage (V) across it. In forward bias, the diode conducts current exponentially after a threshold voltage (typically 0.7V for silicon diodes). In reverse bias, only a tiny leakage current flows until breakdown occurs at a high reverse voltage. This asymmetric behavior enables diodes to act as one-way current devices.
Semiconductor diode I-V characteristics
The I-V characteristics of a semiconductor diode describe the relationship between the current (I) flowing through the diode and the applied voltage (V) across it. In forward bias, the diode conducts current exponentially after a threshold voltage (typically 0.7V for silicon diodes). In reverse bias, only a tiny leakage current flows until breakdown occurs at a high reverse voltage. This asymmetric behavior enables diodes to act as one-way current devices.
💡 Key Takeaways
- Explain the forward and reverse bias regions of a diode and how they shape the I-V curve.
- Describe the diode equation I = I_s (e^(V/(nV_t)) - 1) and what each term represents (saturation current I_s, ideality factor n, thermal voltage V_t).
- Identify the approximate forward knee voltage for silicon diodes (~0.6–0.7 V) and how current rises rapidly after that.
- Explain how temperature and non-idealities (e.g., series resistance, leakage, breakdown) affect the I-V characteristics.
❓ Frequently Asked Questions
What does the diode I-V characteristic represent?
It shows how current responds to applied voltage in forward and reverse directions: current rises rapidly under forward bias after a knee voltage, while reverse current remains small until breakdown.
What happens in forward bias?
The depletion region narrows and charge carriers cross more easily, causing current to increase exponentially with voltage. For silicon, the practical forward drop is about 0.6–0.7 V at moderate current (lower at light load, higher at high current).
What happens in reverse bias and what is breakdown?
In reverse bias, the current is very small (reverse saturation current). If the reverse voltage becomes large enough, breakdown occurs and current rises sharply; some diodes (like Zeners) are designed to operate safely in breakdown regions.
What is the Shockley diode equation and its key parameters?
I = I_s (e^(V/(nV_T)) − 1). Here I_s is the saturation current, n is the ideality factor (~1–2), and V_T ≈ 25 mV at room temperature. It explains the forward exponential rise and the small reverse current; at high forward voltages, series resistance limits the current.
